Molded Teflon Ptfe Sheet Low Friction 100% Virgin PTFE
Product number:Molded Teflon Ptfe Sheet Low Friction 100% Virgin PTFE 1000*1000mm
Quick Overview: Place of Origin: China (Mainland) Certification: SGS,IOS9001,ISO14001
Send Inquiry
PDF DownLoad
Product Description
Teflon ptfe skived sheet is manufactured by technique of compacting, sintering, rotary cutting
with PTFE granular resin. Teflon ptfe moulded sheet is manufactured by molding process with PTFE regular resin and sintering.Teflon ptfe sheet is very suitable for seals,lining,diaphragm,spacer guide and bearing pad for bridge.
Teflon ptfe sheet has good dielectric performance and non-aging, best anti chemistry corrosion
ability and wide applying intension range.
Main Feature:
1. Heat resistance property---It is able to wok stably between -180°C to +260°C.
2. Excellent non-sticky property---It easier to remove those resin, dopes, oil and other sticky things.
3. Good mechanical property with no distortion and low friction coefficient.
4. Excellent insulation property.
5. Materials like carbon, graphite and glass fiber can be filled.
6. Virgin and recycled materials are available
Filler:
Glass Fiber:
Increases compressive strength, rigidity and wear.
Carbon:
Increases compressive strength, hardness, wear, and load properties.
Graphite:
Reduces coefficient of friction
Molybdenum Disulfide:
Increases hardness, stiffness, and wear
Bronze:
Increases hardness and wear resistance
Reduces creep and cold flow
Minimal effect on chemical and electrical properties
Good chemical resistance
Various types and amounts of carbon can be added to alter conductivity
Reduces initial wear
Increases strength
Minimal effect on chemical and electrical properties
Increases dimensional stability and compressive strength
Not suitable for corrosive or electrical applications
Technical data:
|
ITEM |
Result |
Unit |
|
Material |
100% Virgin PTFE |
|
|
Apparent density |
2.10-2.30 |
g/ cm3 |
|
Tensile Strength |
22-28 |
Mpa |
|
Ultimate Elongation |
250-300 |
% |
|
Tempature Resist |
-180-+260 |
oC |
|
PTFE Molded sheet Thickness |
2.0mm-----100mm |
|
|
Molded sheet Length * width |
Min Dimension=300x300mm, Max Dimension= 2000x2000mm Other sizes based on your requirements |
|
|
PTFE Skived sheet thickness |
0.1mm-----8.0mm |
|
|
PTFE Skived sheet width(Max) |
2700mm |
|
