				 Glass Fiber:  |


					Increases compressive strength, rigidity and wear.  |

|
				 Carbon:  |


					Increases compressive strength, hardness, wear, and load properties.  |

|
				 Graphite:  |


					Reduces coefficient of friction  |

|
				 Molybdenum Disulfide:  |


					Increases hardness, stiffness, and wear  |

|
				 Bronze:  |


					Increases hardness and wear resistance  |

| Product No. | Filled compound and content by weight | Tension strength MPa min | Ultimate strength% min | Compresive strength MPa min |
| 1 | 20% glass fiber | 10 | 120 | 16 |
| 2 | 25% glass fiber | 10 | 100 | 16 |
| 3 | 20% glass fiber graphile | 10 | 120 | 16 |
| 4 | 60% bronze | 10 | 80 | 20 |
| 5 | 15% carbon fiber | 11 | 130 | 16 |
| 6 | 24% bronze 12%glass fiber 6% graphite | 9 | 100 | 16 |
| 7 | 15%glass fiber 105polyikmide 5% graphite | 10 | 120 | 16.7 |
| Item Name | Precision Part | ||||
| Quality Assurance | ISO9001:2008 Certified | ||||
| Machining Equipment | Machining Center / CNC Lathes / Grinding Machines / Milling Machines / Lathes / Wire-cuts / Laser Cuts / CNC Shearing Machines / CNC Bending Machines / etc. | ||||
| Materials | Aluminum Alloy: | ||||
| 5052 /6061/ 6063 / 2017 / 7075 / etc. | |||||
| Brass Alloy: | |||||
| 3602 / 2604 / H59 / H62 / etc. | |||||
| Stainless Steel Alloy: | |||||
| 303 / 304 / 316 / 412 / etc. | |||||
| Steel Alloy: | |||||
| Carbon Steel / Die Steel / etc. | |||||
| Other Special Materials: | |||||
| Lucite / Nylon / Bakelite / etc. | |||||
| We handle many other type of materials. Please contact us if your required material is not listed above. | |||||
| Surface Treatment | Blacking,polishing,anodize,chrome plating,zinc plating,nickel plating,tinting | ||||
| Inspection | Our Mitutoyo Tool Microscope can measure up to 300mmX x 175mmY x 220mmZ | ||||
| File Formats | Solid Works,Pro/Engineer, AutoCAD(DXF,DWG), PDF,TIF etc. | ||||
	Specification


1.the best chemical resistance properties
2. long-term using of temperature
3.reach 260 degrees
4.have very good self-lubricating
5.electrical flame retardant
6.commonly used in the food machinery, textile machinery, engineering machinery
